    Hidden parameters on Fanuc 0T?

    Just wondering could there be a parameter library in my Fanuc OT control that I can't see by pressing the parameter key and scrolling? The reason I ask is I though I don't have a parameter manual my maintenance manuals list all the parameters I can find on the screen, yet flipping all the pages and reading the descriptions I can't find parameters for turning down the rapid feed rates or any accelerationdeceleration parameters. My machine only displays parameters 001-999 and 8100-8299. I found an 0i parameter list that shows 1400's and 1600's controlling these settings. Unfortunately my controller is a 1993 that appears to be 2 years before Fanucs had the descriptions on the screen next to the parameter numbers. My controller doesn't have a system key or a soft key for parameter number search.
  2. Titanium
    Join Date
    Feb 2006
    Location
    Republic of Texas
    Posts
    2,446
    Post Thanks / Like
    I would like an answer to this question, too. My 0T-C has 900 parameters that only go to 919 and an option I am supposed to have is supposedly on 923. Hard to turn it on when you don't have the parameter.
  3. Hot Rolled
    Join Date
    Mar 2011
    Country
    SWITZERLAND
    Posts
    982
    Post Thanks / Like
    Likes (Given)
    118
    Likes (Received)
    399
    Horrible subject, I stumbled over that, too. In my case there was a set of X and Z parameters in a mask that prevented the tool from moving closer towards the chuck than, what was it, 26 and 10 mm, respectively (or so). The programmer made codes with the tool moving from center outwards for planing! I almost went berserk since I wasn’t able ONE to set the values to Zero, and TWO to find back to that page. The boss was the programmer. He had absolutely no sense for giving me a chance on the issue, so I had to watch the inserts go whining with an cutting angle of 5 degrees!
    There must be access to those parameters. Problem is that paperwork and control are never made by the same person. You need a knowledgeable Fanuc representative.
  4. Plastic
    Join Date
    Apr 2012
    Location
    Antalya, Turkiye
    Posts
    1
    Post Thanks / Like
    Likes (Given)
    0
    Likes (Received)
    0
    do you set PWE=1 first. I have an O-TT control on a Mori ZL 15 SMC.
  5. Dualkit
    Diamond
    Join Date
    Apr 2005
    Location
    Beaverdam, Virginia
    Posts
    7,136
    Post Thanks / Like
    Likes (Given)
    572
    Likes (Received)
    3308
    Originally Posted by ubekci
    do you set PWE=1 first. I have an O-TT control on a Mori ZL 15 SMC.
    Yes, enabling rewrite does not change the number of displayed parameters.
  6. Titanium
    Join Date
    Feb 2006
    Location
    Republic of Texas
    Posts
    2,446
    Post Thanks / Like
    You really need to get the parameter manual. Mine came from GE-Fanuc: GFZ-61400E/03. It is for an 0T-C.
  7. Plastic
    Join Date
    Dec 2011
    Location
    Houston, TX
    Posts
    2
    Post Thanks / Like
    Likes (Given)
    0
    Likes (Received)
    1
    Did you ever figure this out? I'm having the same problem.
